Pub. 42004-488C
M ODEL LE300-IP P AGE /P ARTY
®
L INE E XTENDER P AGE 51 of 68
e:\standard ioms - current release\42004 instr. manuals\42004-488c.doc
09/14
Designator Type Function
SW2 8-position
DIP switch
Position 1 - T1 line build out bit 0
Position 2 - T1 line build out bit 1
Position 3 - T1 line build out bit 2
Position 4 - T1/E1 receive equalizer gain limit
Position 5 - Page audio hold time (bit 1)
Test waveform select (bit 1)
Position 6 - Page audio hold time (bit 2)
Test waveform select (bit 2)
Position 7 - Page audio detect threshold
Test waveform select (bit 2)
Position 8 - Test waveform enable
SW3 8-position
DIP switch
Position 1 - T1/E1 clock source (master/slave)
Position 2 - T1/E1 clock source (master/slave)
Position 3 - LVDS “in” (enabled/disabled)
Position 4 - LVDS “out” (enabled/disabled)
Position 5 - 600-ohm audio monitor volume (bit 1)
Position 6 - 600-ohm audio monitor volume (bit 2)
Position 7 - 600-ohm audio monitor volume (bit 3)
Position 8 - 600-ohm audio monitor volume (bit 4)
SW4 8-position
DIP switch
Position 1 - Party Line 5 (connect/disconnect)
Position 2 - Party Line 4(connect/disconnect)
Position 3 - Party Line 3 (connect/disconnect)
Position 4 - Party Line 2 (connect/disconnect)
Position 5 - Party Line 1 (connect/disconnect)
Position 6 - Page line (connect/disconnect)
Position 7 - Page line monitor output (connect/disconnect)
Position 8 - Not used
SW5 8-position
DIP switch
Position 1 - SmartSeries Page Line FSK data (enable/disable)
Position 2 - 50 kHz Page Line VLC signal (enable/disable)
Position 3 - Regenerate page line ground fault (enable/disable)
Position 4 - GND fault contact activates on local page line fault.
Position 5 - GND fault contact activates on remote page line fault.
Position 6 - Page audio contact activates on local page line audio.
Position 7 - Page audio contact activates on remote page line audio.
Position 8 - T1 or E1 mode selection
SW6 4-position
DIP switch
Position 1 - One minute startup delay of echo cancellation training
(enable/disable)
Position 2 - Local party line off-hook regeneration (enable/disable)
Position 3 - On-hook party line muting (enable/disable)
Position 4 - Mute all audio lines (enable/disable)
