When using GAI-Tronics 60029 Series system cable, follow the wiring color code as shown in Table 27
below:
Table 27. Color Codes for GAI-Tronics 60029 Series System Cable
Terminal
Designator GTC System Cable
Color Code
Description
P5-1/P8-1 PAGE - L1 Red/Blue
Page Line audio
P5-2/P8-2 PAGE - L2 Blue/Red
P5-3/P8-3 PARTY 1 - L1 Red
Party Line 1 audio
P5-4/P8-4 PARTY 1 - L2 Tan/red
P5-5/P8-5 PARTY 2 - L1 Violet
Party Line 2 audio
P5-6/P8-6 PARTY 2 - L2 Tan/violet
P5-7/P8-7 PARTY 3 - L1 Blue
Party Line 3 audio
P5-8/P8-8 PARTY 3 - L2 Tan/blue
P5-9/P8-9 PARTY 4 - L1 Brown
Party Line 4 audio
P5-10/P8-10 PARTY 4 - L2 Tan/brown
P5-11/P8-11 PARTY 5 - L1 Yellow
Party Line 5 audio
P5-12/P8-12 PARTY 5 - L2 Tan/yellow
