Testing and Troubleshooting
Generating Audio Test Signals
The Model LE300-IP Line Extender is capable of generating several testing waveforms onto the audio
lines of the Page/Party
® system to aid in system testing and troubleshooting. Rotary switch SW1 on the
Main PCBA determines which Page/Party ® audio line will receive the test waveform. DIP switch SW2
determines which testing waveform is generated. Closing DIP switch SW2-8 enables the test waveform.
Switches SW2-5 through SW2-7 select a test waveform. Note that the frequency selections are different
on the selected audio party line. Refer to tables below for valid switch settings.
Table 43.
SW1 Selected
Page/Party ® Line
Selected Tone SW2-5 SW2-6 SW2-7 SW2-8
1 Party Line #1 7 kHz (sine wave) Open Open Open Closed
6 Page Line 4 kHz (sine wave) Closed Open Open Closed
2 kHz (sine wave) Open Closed Open Closed
1 kHz (sine wave) Closed Closed Open Closed
500 Hz (sine wave) Open Open Closed Closed
125 Hz (sine wave) Closed Open Closed Closed
1 kHz (saw tooth wave) Open Closed Closed Closed
31 Hz pulses Closed Closed Closed Closed
SW1 Selected
Page/Party ® Line
Selected Tone SW2-5 SW2-6 SW2-7 SW2-8
2 Party Line #2 3.5 kHz (sine wave) Open Open Open Closed
3 Party Line #3 2.0 kHz (sine wave) Closed Open Open Closed
4 Party Line #4 1.0 kHz (sine wave) Open Closed Open Closed
5 Party Line #5 500 Hz (sine wave) Closed Closed Open Closed
250 Hz (sine wave) Open Open Closed Closed
125 Hz (sine wave) Closed Open Closed Closed
1 kHz (saw tooth wave) Open Closed Closed Closed
31 Hz Pulses Closed Closed Closed Closed
N OTE : Remember to restore SW1 to “0” and SW2 to its initial setting when no longer generating test
signals.
