GAI-Tronics LE300-IP Page/Party Line Extender - Manual (Page 57)

Pub. 42004-488C
M ODEL LE300-IP P AGE /P ARTY
®
L INE E XTENDER P AGE 54 of 68
e:\standard ioms - current release\42004 instr. manuals\42004-488c.doc
09/14
Table 40. DIP Switch SW5 on Main PCBA
Switch Setting Note
SW5-1 Enable FSK data for SmartSeries systems
SW5-2 Enable 50 kHz VLC
SW5-3 Regenerate page line ground fault
SW5-4 Local ground fault activates output contact
SW5-5 Remote ground fault activates output contact
SW5-6 Local page audio activates output contact
SW5-7 Remote page audio activates output contact
SW5-8 Select T1 mode or E1 mode
Table 41. DIP Switch SW6 on Main PCBA
Switch Setting Note
SW6-1 Startup delay of echo cancellation training
SW6-2 Local party line off-hook regeneration
SW6-3 On-hook party line muting
SW6-4 Mute analog circuits
Table 42. T1/E1 Line Grounding on Main PCBA
Header Setting Note
P20 T1/E1 Line receive
P21 T1/E1 Line transmit
