ICP9000 Navigator Installation and Service Manual Foreword
9 12/10
Specifications
General
Temperature range .................................................................................................................. 0º C to +50º C
Humidity ................................................................................................................................... 95% at 50º C
Physical size............................................................................................. 8.75 H
× 17 W × 11.125 D inches
Rack-mount size........................................................................................................................................ 5U
Power input ............................................... 120/240 V ac, +15%; 47 to 63 Hz with external power module;
or +10.5 to 18 V dc
Weight (without options)
ICPN9004A ..........................................................................................................................20.5 lbs.
ICPN9008A .............................................................................................................................22 lbs.
ICPN9012A ..........................................................................................................................23.5 lbs.
Audio General
Audio response.............................................................. +3 dB at 300 to 3000 Hz (except guard tone notch)
Hum and noise ...............................................................Transmit – Less than 50 dB below full rated power
Receive – Less than 55 dB below full rated power
Audio distortion ............................................................................................................... Less than 2% THD
Compression ........................................................................................ Normalizes input variations of 30 dB
Receiver Audio
Input ............................................................................................. −25 dBm to +11 dBm, selectable in steps
Cross-talk .............................................................. 60 dB below rated output levels at rated line impedance
Input impedance................................................................................................................ 600 ohms nominal
Tone Remote Control
Guard tone................................................................................ 2100, 2175, 2325, 2800 (default = 2175 Hz)
Function tones........................................................................... 1950, 1850, 1750, 1650, 1550, 1450, 1350,
1250, 1150, 1050, 950, 850, and 750
Default function tones................................................................................................ F1 Transmit: 1950 Hz
F2 Transmit: 1850 Hz
F3 Transmit: 1350 Hz
F4 Transmit: 1250 Hz
Monitor: 2050 Hz
Functional tones are selectable via GAI-Tronics’ CARD Suite Software Application
