ICP9000 Navigator Installation and Service Manual Paging
69 12/10
Table 20. Code Plans
Important Note: The 1
st
digit indicates Chart A Group # Source for the A tone, and the 2
nd
digit
indicates Chart A Group # Source for B Tone.
MSD Digit of 3 Digit Capcode Code
Plan 0 1 2 3 4 5 6 7 8 9
Gen Enc 42 11 22 12 44 55 21 45 54 24
Gen Enc
Modified
42 11 22 33 44 55 66 DD EE FF
B
N/A 11 22 33 12 13 21 31 23 32
C N/A 11 22 12 44 14 21 41 24 42
D N/A 11 22 12 15 55 21 51 25 52
E N/A 11 22 12 21 16 66 61 26 62
F N/A 11 13 33 44 31 14 41 34 43
G N/A 11 13 33 31 55 15 51 35 52
H N/A 11 13 33 31 16 66 61 36 63
J N/A 11 14 41 44 55 15 45 54 51
K N/A 11 14 41 44 16 66 61 46 64
L N/A 11 15 51 16 55 66 61 56 65
M N/A 23 22 33 44 32 24 42 34 43
N N/A 23 22 33 32 55 25 52 35 53
P N/A 23 22 33 32 26 66 62 36 63
Q N/A 24 22 42 44 55 25 45 54 52
R N/A 24 22 42 44 26 66 62 46 64
S N/A 25 22 52 26 55 66 62 56 65
T N/A 34 43 33 44 55 35 45 54 53
U N/A 34 43 33 44 36 66 63 46 64
V N/A 35 53 33 36 55 66 63 56 65
W N/A 46 64 56 44 55 66 45 54 65
Y N/A 77 88 99 78 79 87 97 89 98
GE AA BA BB AB CC CA CB AC BC N/A
SP 99 AA BB DD 9D D9 AD DA BD DB
