Paging
ICP9000 Navigator Installation and Service Manual
12/10 72
Table 22. Plectron Paging Code Plan Chart
Most Significant Digits-to-Tone Source
1
st
2 (MS)
Digits
00 01 02 03 04 05 06 07 08 09 10 11 12 13 14 15 16 17
3
rd
digit tone
source
P1 P2 P1 P2 P3 P1 P3 P2 P3 P4 P1 P4 P2 P4 P3 P4 P5 P1
4
th
digit tone
source
P1 P2 P2 P1 P3 P3 P1 P3 P2 P4 P4 P1 P4 P2 P4 P3 P5 P5
1
st
2 (MS)
Digits
18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35
3
rd
digit tone
source
P5 P2 P5 P3 P5 P4 P5 P6 P1 P6 P2 P6 P3 P6 P4 P6 P5 P6
4
th
digit tone
source
P1 P5 P2 P5 P3 P5 P4 P6 P6 P1 P6 P2 P6 P3 P6 P4 P6 P5
Table 23. Plectron Tone Group/Frequency Chart (in Hz)
3rd and 4th
Digits
0
1
2
3
4
5
6
7
8
9
Tone Group P1
643 672 701 732 765 799 834 871 910 950
Tone Group P2
992 1036 1082 1130 1180 1232 1287 1344 1403 1465
Tone Group P3
1530 1598 1669 1743 1820 1901 1985 2073 2164 2260
Tone Group P4
2361 2465 2575 2688 2807 2932 3062 3197 3339 3487
Tone Group P5
282.2 294.7 307.8 321.4 335.6 330.5 366.0 382.3 399.2 416.9
Tone Group P6
435.3 454.6 474.8 495.8 517.8 540.7 564.7 589.7 615.8 742.5
