Introduction Specifications
Page 1-14 MDE-5013C TopKAT™ PLUS Installation Manual · February 2015
Specifications
The physical, electrical, and environmental specifications applicable to the TopKAT PLUS are
displayed in the following table.
Description Specification
Supply Voltage 120-240 VAC
Power Consumption 1 A max
Operating Temperature -40 °F to +104 °F (-40 °C to +40 °C)
Storage Temperature -40 °F to +158 °F (-40 °C to +70 °C)
Humidity 80% Non-condensing
Dimensions W X H X D: 16.26 X 11.24 X 17.224” (413 X 285.5 X 437.5 mm)
Communication Interface RS-485 - 9600 bps, Half-duplex

RS-232 
Ethernet RJ-45 - 10 mbps
Pump Control Maximum Current [2 Solid State
Relay Channels, (see note)] Motor Maximum: 3/4 HP at 115 VAC or 1-1/2 HP at 230 VAC
Power Supply Output Voltage to Pulser Unit 12 VDC +/- 20%
Power Supply Maximum Output Current 30 mA max
Pulsar Input High Level Voltage 9 to 15 VDC
Pulsar Input High Level Sink Current (at 15 V) 3 mA
In Use “On” Level (Input) 100-240 VAC, 50/60 Hz, 2 W (20 mA)
In Use “Off” Level (Input) 0 to 20 VAC
UL ® Recognition Suitable for Use Over Class 1, Division 2, Group D
Note: When controlling 230 VAC pumps the solid state relay only controls one leg of the 230 VAC.
Standards
Communication Standards
TopKAT PLUS communicates, in its different models, over the following standards:
• RS-232 link
• RS-485 link
• TCP/IP over Ethernet
Security Standards
TDES encryption for payment devices (contactless tags, magnetic stripe cards, and so on).
