TopKAT PLUS Installation Procedures
Connections to TopKAT PLUS - Pedestal Mounted Units
Page 3-10
MDE-5013C TopKAT™ PLUS Installation Manual · February 2015
Figure 3-8: TopKAT PLUS Terminal Block - Electronic Pump (Pedestal Mount)
For the electronic TopKAT factory-installed on top of an Atlas 9800, all the required
wiring for the 9800 electronic pumps including the RS-485 communication, the LAN
communications, and AC power is pre-wired from the factory. No other connections are
made to the terminal blocks.
IMPORTANT INFORMATION
