MDE-5013C TopKAT™ PLUS Installation Manual · February 2015 Page 1-1
Purpose Introduction
1 – Introduction
Purpose
This manual provides installation instructions for TopKAT ™ PLUS, the complete station
automation solution in a dispenser-mounted compact box. The system must be installed in the
factory as described in this manual to ensure its reliability and proper operation.
This manual includes a general and functional description of the product, its main
components, installation requirements, and procedures.
Intended Users
This manual is intended for Authorized Service Contractors (ASCs) of TopKAT PLUS and its
components. It is also intended for the factory and island electricians.
Description
TopKAT PLUS is a fuel control and data acquisition system. The system is self-contained in a
forecourt compatible and weather-resistant cabinet installed on top of Gasboy
® dispensers or
mounted on a post.
TopKAT PLUS (see Figure 1-1 on page 1-2 ) is a core component in Gasboy’s solution for
small home base gas stations. TopKAT PLUS provides the central function of site controller
adequate for a maximum of two nozzles in a single dispenser. It also fulfills other essential
services on the island such as driver identification system, transaction data storage, and so on.
Its ergonomic design, as well as its user-friendly operating program, enables fast and accurate
service for the driver in the refueling site.
TopKAT PLUS is equipped with the Outdoor Payment Terminal (OrPT), a payment terminal
and communication receptacle. The payment terminal is equipped with an alphanumeric
Liquid Crystal Display (LCD) and a keyboard to interface with the client. This enables
TopKAT PLUS to support all common refueling identification devices such as magnetic cards,
contactless Radio Frequency Identification (RFID) tags (also known as MIFARE
® tags), and
keypad entry.
