TopKAT PLUS Installation Procedures Installation Specifications
Page 3-2 MDE-5013C TopKAT™ PLUS Installation Manual · February 2015
Types of Cables
Following table lists the types of cable in use for the wiring of the TopKAT PLUS system:
No. Function Type
1 AC Power Power Cable, 3 X 1.5 mm 2 NYY (14 AWG), in accordance with local
standards.
Control to Pumps (Valves or Engine)
In Use Signal
2 Pulser Data Communication Cable, 300 V RMS, 194 ºF (90 ºC), Shielded
Twisted-pair, Oil-resistant, 24 AWG, Low Capacitance below

60 PF/meter similar to Belden ® 9729 Cable
3 LAN Category-5E (CAT-5E), Four Conductor Insulator Cable (042GA00007
or 042GALF007 - Gilbarco part number M12673B001) or Shielded,
300 V RMS, 194 ºF (90 ºC) similar to Belden 121700A
4 GND Ground Cable 0.4” (10.8 mm 2 )
Note: Use the appropriate gauge wire size for the AC power for pumps, dispensers, and fueling equipment.
Types of TopKAT PLUS Units
There are three types of TopKAT PLUS configurations as follows:
• Electronic TopKAT PLUS mounted on an Atlas 9800 unit
• Electronic TopKAT PLUS mounted on a pedestal
• Mechanical TopKAT PLUS mounted on a pedestal
Head Assembly Dimensions
The TopKat PLUS head assembly that is mounted on a pedestal or Atlas 9800 electronic pump
is 116.5 X 11.4 X 18” (W X H X D).
Allow a minimum of 20-inches clearance at rear of the TopKat PLUS head assembly for
pedestal and Atlas mounted units.
IMPORTANT INFORMATION
