LSI53C895A PCI to Ultra2 SCSI Controller 2-1
Chapter 2
Functional Description
Chapter 2 is divided into the following sections:
•
Section 2.1, “PCI Functional Description”
•
Section 2.2, “SCSI Functional Description”
•
Section 2.3, “Parallel ROM Interface”
•
Section 2.4, “Serial EEPROM Interface”
•
Section 2.5, “Alternative SSVID/SSID Loading Mechanism”
•
Section 2.6, “Power Management”
The LSI53C895A PCI to Ultra2 SCSI Controller is composed of the
following modules:
•
32-bit PCI Interface with 64-bit addressing
•
PCI-to-Wide Ultra2 SCSI Controller
•
ROM/Flash Memory Controller
•
Serial EEPROM Controller
Figure 2.1 illustrates the relationship between these modules.
