2-58

Functional Description

2.4.2 No Download Mode

When MAD7 is pulled up through an external resistor, the automatic
download is disabled and no data is automatically loaded into chip
registers at power-up. The Subsystem ID and Subsystem Vendor ID
registers are read only, per the PCI specification, with a default value of
0x1000 and 0x1000 respectively.

2.5 Alternative SSVID/SSID Loading Mechanism

Programming the PCI

Subsystem ID

and

Subsystem Vendor ID

registers

can be accomplished in the LSI53C895A without the use of a serial
EEPROM. This alternative loading mechanism is the only way to set the
SSVID/SSID registers to something other than the default value, except
through Serial EEPROM download.

Please see

Section 2.4, “Serial EEPROM Interface,”

for additional

information.

Table 2.8

Mode A Serial EEPROM Data Format

Byte

Name

Description

0xFB

SVID(0)

Subsystem Vendor ID

, LSB. This byte is loaded into the least significant

byte of the Subsystem Vendor ID register in the appropriate PCI
configuration space at chip power-up.

0xFC

SVID(1)

Subsystem Vendor ID, MSB. This byte is loaded into the most significant
byte of the Subsystem Vendor ID register in the appropriate PCI
configuration space at chip power-up.

0xFD

SID(0)

Subsystem ID

, LSB. This byte is loaded into the least significant byte of

the Subsystem ID register in the appropriate PCI configuration space at
chip power-up.

0xFE

SID(1)

Subsystem ID, MSB. This byte is loaded into the most significant byte of
the Subsystem ID register in the appropriate PCI configuration space at
chip power-up.

0xFF

CKSUM Checksum. This 8 bit checksum is formed by adding, bytewise, each byte

contained in locations 0x00–0x03 to the seed value 0x55, and then taking
the 2’s complement of the result.

0x100–0xEOM UD

User Data.
