Package Diagrams 6-67
Table 6.52 BGA Pin List Alphabetically
VDD D11
VDD D15
VDD F4
VDD F17
VDD K4
VDD L17
VDD R4
VDD R17
VDD U6
VDD U10
VDD U15
VDD
RBIAS
A11
VDDA H19
VDDCORE P1
VDDCORE P2
VDDCORE P17
VDDCORE R19
VSS A1
VSS D4
VSS D8
VSS D13
VSS D17
VSS H4
VSS H17
VSS J9
VSS J10
VSS J11
VSS J12
VSS K9
VSS K10
VSS K11
VSS K12
VSS L9
VSS L10
VSS L11
VSS L12
VSS M9
VSS M10
VSS M11
VSS M12
VSS N4
VSS N17
VSS U4
VSS U8
VSS U13
VSS U17
VSSA J18
VSSCORE M3
VSSCORE N18
VSSCORE P20
VSSCORE2 N1
Signal Pin Signal Pin
AD0 V20
AD1 U18
AD2 V18
AD3 Y19
AD4 V17
AD5 Y18
AD6 W17
AD7 Y17
AD8 W15
AD9 Y15
AD10 W14
AD11 Y14
AD12 V13
AD13 W13
AD14 Y13
AD15 V12
AD16 Y8
AD17 W8
AD18 V8
AD19 Y7
AD20 W7
AD21 V7
AD22 Y6
AD23 W6
AD24 W5
AD25 V5
AD26 Y3
AD27 V3
AD28 W1
AD29 V2
AD30 V1
AD31 U2
ALT_IRQ/ Y2
C_BE0/ Y16
C_BE1/ W12
C_BE2/ U9
C_BE3/ Y5
CLK T1
DEVSEL/ Y10
DIFFSENS H20
FRAME/ V9
GNT/ T2
GPIO0
FETCH/
T19
GPIO1
MASTER/
R18
GPIO2 R20
GPIO3 P18
GPIO4 P19
GPIO5 W19
GPIO6 W20
GPIO7 V19
GPIO8 W2
IDSEL V6
IRDY/ W9
IRQ/ U20
MAC/
TESTOUT
K19
MAD0 K20
MAD1 L20
MAD2 L19
MAD3 M20
MAD4 M19
MAD5 M18
MAD6 N20
MAD7 N19
MAS0/ M2
MAS1/ M1
MCE/ R1
MOE/ N3
MWE/ N2
No Connect A2
No Connect A6
No Connect A19
No Connect A20
No Connect B1
No Connect B11
No Connect B17
No Connect B18
No Connect C2
No Connect C3
No Connect C4
No Connect C5
No Connect C6
No Connect C7
No Connect C8
No Connect C9
No Connect C11
No Connect C12
No Connect C13
No Connect C14
No Connect C15
No Connect C16
No Connect C18
No Connect D5
No Connect D7
No Connect D9
No Connect D10
No Connect D12
No Connect D14
No Connect E2
No Connect E3
No Connect E4
No Connect E18
No Connect F18
No Connect G3
No Connect G4
No Connect G17
No Connect G18
No Connect H3
No Connect H18
No Connect J1
No Connect J4
No Connect J17
No Connect K3
No Connect K17
No Connect K18
No Connect L4
No Connect L18
No Connect M4
No Connect M17
No Connect P3
No Connect P4
No Connect R3
No Connect T3
No Connect T4
No Connect T17
No Connect T18
No Connect T20
No Connect U3
No Connect U5
No Connect U7
No Connect U12
No Connect U14
No Connect U16
No Connect U19
No Connect V4
No Connect V10
No Connect V14
No Connect V15
No Connect V16
No Connect W3
No Connect W4
No Connect W16
No Connect W18
No Connect Y4
No Connect Y9
No Connect Y11
No Connect Y20
PAR Y12
PERR/ V11
RBIAS A10
REQ/ U1
RST/ R2
SACK
−
B14
SACK+ A14
SACK2
−
D2
SACK2+ D3
SATN
−
B12
SATN+ A12
SBSY
−
B13
SBSY+ A13
SCD
−
C17
SCD+ D16
SCLK J20
SD0
−
C1
SD0+ D1
SD1
−
B3
SD1+ B2
SD2
−
B4
SD2+ A3
SD3
−
B5
SD3+ A4
SD4
−
B6
SD4+ A5
SD5
−
A7
SD5+ B7
SD6
−
A8
SD6+ B8
SD7
−
A9
SD7+ B9
SD8
−
D20
SD8+ D19
SD9
−
E20
SD9+ E19
SD10
−
F20
SD10+ F19
SD11
−
G20
SD11+ G19
SD12
−
J3
SD12+ J2
SD13
−
H2
SD13+ H1
SD14
−
G2
SD14+ G1
SD15
−
F2
SD15+ F1
SDP0
−
B10
SDP0+ C10
SDP1
−
E1
SDP1+ F3
SERR/ U11
SIO
−
C20
SIO+ E17
SMSG
−
B16
SMSG+ A16
SREQ
−
D18
SREQ+ C19
SREQ2
−
B20
SREQ2+ B19
SRST
−
B15
SRST+ A15
SSEL
−
A18
SSEL+ A17
STOP/ W11
TCK K1
TDI L3
TDO L2
TEST_HSC/ J19
TEST_RST/ K2
TMS L1
TRDY/ W10
TRST Y1
VDD D6
Signal Pin Signal Pin Signal Pin
1. NC pins are not connected.
