Page 171
SCSI Registers
4-59
Version 3.3
Copyright © 1998–2003 by LSI Logic Corporation. All rights reserved.
CLF
Clear DMA FIFO
2
When this bit is set, all data pointers for the DMA FIFO
are cleared. Any data in the FIFO is lost. After the
LSI53C896 SCSI function successfully clears the
appropriate FIFO pointers and registers, this bit
automatically clears.
Note:
This bit does not clear the data visible at the bottom of
the FIFO.
FM
Fetch Pin Mode
1
When set, this bit causes the FETCH/ pin to deassert
during indirect and table indirect read operations.
FETCH/ is only active during the opcode portion of an
instruction fetch. This allows the storage of SCRIPTS in
a PROM while data tables are stored in RAM.
If this bit is not set, FETCH/ is asserted for all bus cycles
during instruction fetches.
WRIE
Write and Invalidate Enable
0
This bit, when set, causes the issuing of Write and
Invalidate commands on the PCI bus whenever legal. The
Write and Invalidate Enable bit in the PCI Configuration
register must also be set in order for the chip
to generate Write and Invalidate commands.
Registers: 0x1C–0x1F
Temporary (TEMP)
Read/Write
TEMP
Temporary
[31:0]
This 32-bit register stores the Return instruction address
pointer from the Call instruction. The address pointer
stored in this register is loaded into the
register when a Return
instruction is executed. This address points to the next
instruction to execute. Do not write to this register while
the LSI53C896 SCSI function is executing SCRIPTS.
31
0
TEMP
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
