SSi 9120 Touchscreen Interface
4586 – 9120 With Touch Screen Interface
Page 71 of 80
Appendix A - PID Loop Factory Default Configurations
% Carbon
Loop 1 Prop Band (DB ON/ OFF)
20.0
LP 1 Reset
0.10
LP 1 Rate
0.00
LP 1 Mode
Dual Reverse
LP 1 Integral Preset
0
LP 1 Cycle Time
16
LP 1 Low Limit
-100
LP1 High Limit
100
LP 1 Zero SP stops control
YES
Loop 2 Prop Band (DB ON/ OFF)
4.4
LP 2 Reset
0.12
LP 2 Rate
2.16
LP 2 Mode
Single Reverse
LP 2 Integral Preset
0
LP 2 Cycle Time
16
LP 2 Low Limit
0
LP 2 High Limit
100
LP 2 Zero SP stops control
NO
Dewpoint
Loop 1 Prop Band (DB ON/ OFF)
20.0
LP 1 Reset
0.10
LP 1 Rate
0.00
LP 1 Mode
Dual Direct
LP 1 Integral Preset
0
LP 1 Cycle Time
16
LP 1 Low Limit
-100
LP1 High Limit
100
LP 1 Zero SP stops control
NO
Loop 2 Prop Band (DB ON/ OFF)
4.4
LP 2 Reset
0.12
LP 2 Rate
2.16
LP 2 Mode
Single Reverse
LP 2 Integral Preset
0
LP 2 Cycle Time
16
LP 2 Low Limit
0
LP 2 High Limit
100
LP 2 Zero SP stops control
NO
%O2
Loop 1 Prop Band (DB ON/ OFF)
20.0
