Measuring
Angle constructions
Angles can be constructed from:
• An angle • Two lines
Angle constructed from an angle
A duplicate feature can be useful when it becomes desirable to perform
new operations with the original while retaining a copy.
To construct an angle from an existing angle:
1 Touch the Measure Angle icon
2 Touch the desired angle
3 Press the Enter key
4 Press the Finish key
The new angle feature will be constructed over the original angle.
Constructing Features
