194 QC-300 Series User’s Guide
Crosshair timeout delay
When the auto-enter crosshair probe is used, a point is automatically col-
lected by the system each time the stage is moved to position the part
under the crosshair. This automatic point entry is delayed until the stage
has been motionless for a short time to ensure that the crosshair is located
where the user intended. The default delay value will be adequate for
most applications, but can be increased to accommodate more relaxed
probing.
To specify Crosshair Timeout, touch the Crosshair Timeout data field and
enter the desired delay in seconds.
Crosshair delay restart distance
As explained above, automatic point entry is delayed until the stage has been motionless for a short time
to ensure that the crosshair is located where the user intended. However, the delay is restarted again from
the beginning if the stage is moved again before the delay has been completed. The move distance required
to restart the delay is specified by the user by entering it directly into the Crosshair
Distance data field in the current unit of measure.
Auto-enter
crosshair
