150
Chapter 4 General Measuring
To construct a distance between 2 co-axial planes
Step 1
Use the mouse to highlight 2 co-axial planes on the features list.
Step 2
Click the distance button on the measure toolbar.
Step 3
Click OK in the dialog box.
