252
Chapter 6 Templates
Program Template
Use the program template to monitor the steps of a parts program. Green
checkmarks indicate steps succesfully completed and a blue arrow points to the
current step. Loop counts are displayed in the data column. Programs can be
set to run a certain number of times. This is referred to as ‘looping’ and each
individual run is a ‘loop.’
Program templates display information only. No data from the features list can
be imported to the the program template.
To open the program template
Step 1
Select open template from the windows menu.
Step 2
Select program.5ft from the file name list box. The file path is
c:\qc5000\templates.
OR
