Perpendicularity tolerance (lines, cylinders, cones)
Use perpendicularity to establish an orientation tolerance between linear fea-
tures. Perpendicularity tolerancing compares the axial orientation of the se-
lected feature to the axis of a reference feature. The actual tolerance zone is a
cylindrical area around the axis of the tolerence feature. Specify the diameter of
the cylindrical tolerance zone to create the tolerance.
To perform a perpendicularity tolerance
Step 1
Highlight the desired feature in the features list.
NOTE NOTE NOTE NOTE NOTE
Use a linear features only
Use a linear features only Use a linear features only Use a linear features only Use a linear features only. P . P . P . P . Perpendicularity tolerances do not erpendicularity tolerances do not erpendicularity tolerances do not erpendicularity tolerances do not erpendicularity tolerances do not
apply to other types of features. apply to other types of features. apply to other types of features. apply to other types of features. apply to other types of features.
Step 2
Click the perpendicularity button on the tolerance toolbar.
Step 3
Enter a value in the tolerance zone box as shown.
CA CA CA CA CAUTION UTION UTION UTION UTION
Enter tolerance values in the appropriate units of measurement. Enter tolerance values in the appropriate units of measurement. Enter tolerance values in the appropriate units of measurement. Enter tolerance values in the appropriate units of measurement. Enter tolerance values in the appropriate units of measurement.
F
FF FFor example, if you are measuring in metric (mm) enter tolerance or example, if you are measuring in metric (mm) enter tolerance or example, if you are measuring in metric (mm) enter tolerance or example, if you are measuring in metric (mm) enter tolerance or example, if you are measuring in metric (mm) enter tolerance
data in metric (mm). data in metric (mm). data in metric (mm). data in metric (mm). data in metric (mm).
