Chapter 1 Overview
10
Locked/unlocked features
Some parts use more than one reference frame to measure all its features.
Locked features are displayed in their own reference frame. Unlocked fea-
tures are displayed in the current reference frame.
To unlock a feature
Step 1
Click the lock icon in the results window.
To lock a feature
Step 1
Click the lock icon in the results window.
