164
Chapter 5 Advanced Measuring & Output
To measure a line using measure magic (2 points)
Step 1
Probe two points on the line as shown.
Step 2
Click OK in the dialog box.
To measure an arc using measure magic (3 points)
Step 1
Probe three points on the arc as shown.
Step 2
Click OK in the dialog box.
