4.4 OLT Traffic Management
The traffic management panel allows the user to change bridging modes, apply complex
filters, and expose many of the OLTs advanced hardware and software features related to
traffic management.
4.4.1 Bridging Configuration Bridging
This panel facilitates provisioning of the bridging mode for each link, as well as the size of
the dynamic forwarding table on a per link basis. If the bridging mode supports VLAN, the
VLAN tag or tags may be specified using this panel. For certain VLAN modes such as
priority shared VLAN multiple links may be provisioned in the same VLAN. These modes
will make forwarding decisions based on multiple fields such as MAC address and VID.
A link may be provisioned in only one bridging mode. However, multiple links, each
provisioned in a different mode, may be associated with a given egress ONU port.
„ Changing the bridging mode for a particular logical link
Notice that after the bridging mode has been applied the Apply button will change to a grey
color.
