Specifications
Power supply: 12 V DC ( ) (10.8 V to 13.2 V)
42 V ‑ 57 V DC ( ) (PoE power supply)
Current consumption: 0.9 A (XLR IN connector)
0.3 A (PoE power supply)
indicates safety information.
„ „
General
Ambient operating
temperature: 0 °C to 40 °C (32 °F to 104 °F)
Allowable humidity: 20% to 90% (no condensation)
Storage temperature: –20 °C to 50 °C (–4 °F to 122 °F)
Weight: Approx. 1.5 k g (3.3 lb)
Dimensions (W × H × D): 210 mm × 92 mm × 177 mm
(8‑9/32 inches × 3‑5/8 inches × 
6‑31/32 inches)
(excluding protrusions)
„ „ Input/output connectors
DC 12 V IN (XLR 4‑pin)
LAN (RJ‑45) (with LED):
10BASE‑T/100BASE‑TX, PoE input
Connection cable: LAN cable, max. 100 m (328 ft)
z z When connecting the unit via a switching hub:
Straight cable (category 5e), STP (Shielded
Twisted Pair) cable recommended
z z When connecting the unit directly:
Crossover cable (category 5e), STP (Shielded
Twisted Pair) cable recommended
z z REMOTE:
Available only for LAN (RJ45) control
SERIAL CONT (RJ‑45):
RS‑422 (control signals for remote cameras),
TALLY OUT
Connecting cable:
Straight cable (category 5e), max. 1000 m
(3280 ft)
TALLY OUT:
Open collector output (negative logic)
Maximum voltage resistance DC 24 V, Maximum
current 50 mA
TALLY/GPIO (D‑sub 25‑pin, female, inch thread):
TALLY IN : Contact input (Status operation)
GPIO IN : Contact input (Trigger operation)
GPIO OUT : Open collector output (negative logic)
Maximum voltage resistance DC 24 V, Maximum
current 10 mA
z z Refer to page 86 for details about the pin layout.
„ „
LCD panel
3.5 inch LCD (QHD: 960 × 540)
The symbols on this product represent the following:
DC
