Chapter 3: Functional Description—ALTMEMPHY (nonAFI)

3–21

ALTMEMPHY Signals

© January 2010

Altera Corporation

External Memory PHY Interface (ALTMEMPHY) (nonAFI) Megafunction User Guide

mem_d

output

MEM_IF_DWIDTH

Memory data bus. D input to QDR II SRAM device.

mem_dm

output

MEM_IF_DM_WIDTH

Memory write select. BWS# input to QDR II SRAM
device.

mem_dq

input

MEM_IF_DWIDTH

Memory data bus. Q output from QDR II SRAM
device.

mem_dqs

input

MEM_IF_DWIDTH /

MEM_IF_DQ_PER_

DQS

Memory read clock high bits (CQ).

mem_dqsn

input

MEM_IF_DWIDTH /

MEM_IF_DQ_PER_

DQS

Memory read clock low bits (CQn).

mem_doff_n

output

1

Memory DLL disable control.

mem_rps_n

output

MEM_IF_CS_WIDTH

Memory read enable signal.

mem_wps_n

output

MEM_IF_CS_WIDTH

Memory write enable signal.

Note to

Table 3–11

:

(1) Connected to WYSIWYGS/pad atoms.

Table 3–11. I/O Interface to QDR II+/QDR II SRAM

(Note 1)

(Part 2 of 2)

Signal Name

Type

Width

Description

Table 3–12. Clock and Reset Signals for QDR II+/QDR II SRAM (Part 1 of 2)

Signal Name

Type

Width

Description

global_reset_n

(1)

input

1

The asynchronous reset input to the controller. All other
reset signals are derived from resynchronized versions of
this. This signal holds the complete ALTMEMPHY
megafunction, including the PLL, in reset while low.

soft_reset_n

(1)

input

1

The asynchronous reset input to reset controller, for
SOPC Builder use, or to be controlled by other system
reset logic. This signal causes a complete reset of the
PHY, but not the PLL in the PHY. In Arria GX, Stratix II,
and Stratix II GX devices, this signal also resets the PLL
reconfiguration block on a falling-edge detection.

phy_clk

output

1

The ALTMEMPHY megafunction half-rate clock provided
to the user. All user inputs and outputs to the
ALTMEMPHY megafunction are synchronous to this clock
in half-rate designs. However, this clock is not used in
full-rate designs.

pll_ref_clk

input

1

The reference clock input to PLL.

reset_phy_clk_n

(1)

output

1

Asynchronous reset, that is de-asserted synchronously
with respect to the associated phy_clock clock
domain. Use this to reset any additional user logic on that
clock domain.
