Chapter 5 - Module System Descriptions
80 Adept Python Modules User’s Guide, Rev. E
K Configuration
In the K configuration, the first axis is parallel to the work surface and rotated 90 degrees
so that the second axis is perpendicular to the work surface. The second axis’ slide
operates in a vertical ’Z’ motion (perpendicular to the work surface).
Available in the following configurations:
• K1200
• K2300
Figure 5-15. K1200 System
X-Axis
Motion
Z-Axis
Motion
