Roland V-8HD HDMI Video Switcher and UVC-01 USB Capture Device Kit - Manual (Page 106)

106
Appendix
7 Other Parameter Area
6 Memory
Address Parameter Name Sys.Ex.Value Meaning of Value
0AH 00H 00H Memory Load Trigger 00H–17H Memory 1–24 (Write Only)
0AH 00H 01H Memory Save Trigger 00H–17H Memory 1–24 (Write Only)
0AH 00H 02H Memory Initialize Trigger 00H–17H Memory 1–24 (Write Only)
0AH 00H 03H Loaded Memory Number 00H–17H, 7FH Memory 1–24, Last Memory (Read Only)
7 Tally Parameter Area
Address Parameter Name Sys.Ex.Value Meaning of Value
0CH 00H 00H HDMI IN 1 TALLY 00H–02H OFF, PGM, PST (Read Only)
0CH 00H 01H HDMI IN 2 TALLY 00H–02H OFF, PGM, PST (Read Only)
0CH 00H 02H HDMI IN 3 TALLY 00H–02H OFF, PGM, PST (Read Only)
0CH 00H 03H HDMI IN 4 TALLY 00H–02H OFF, PGM, PST (Read Only)
0CH 00H 04H HDMI IN 5 TALLY 00H–02H OFF, PGM, PST (Read Only)
0CH 00H 05H HDMI IN 6 TALLY 00H–02H OFF, PGM, PST (Read Only)
0CH 00H 06H HDMI IN 7 TALLY 00H–02H OFF, PGM, PST (Read Only)
0CH 00H 07H HDMI IN 8 TALLY 00H–02H OFF, PGM, PST (Read Only)
7 Preset Memory Area
You can load or rewrite the stored contents of the preset memories.
* The 2nd byte and 3rd byte of a Preset Memory Area address, and the value range, are in common with the Video Parameter Area (00H 00H 00H) and the Audio Parameter
Area (01H 00H 00H).
Address Parameter Name Meaning of Value
10H 00H 00H Video Parameter (Memory 1) Load/rewrite video parameter stored in Memory 1
11H 00H 00H Audio Parameter (Memory 1) Load/rewrite audio parameter stored in Memory 1
12H 00H 00H Video Parameter (Memory 2) Load/rewrite video parameter stored in Memory 2
13H 00H 00H Audio Parameter (Memory 2) Load/rewrite audio parameter stored in Memory 2
14H 00H 00H Video Parameter (Memory 3) Load/rewrite video parameter stored in Memory 3
15H 00H 00H Audio Parameter (Memory 3) Load/rewrite audio parameter stored in Memory 3
16H 00H 00H Video Parameter (Memory 4) Load/rewrite video parameter stored in Memory 4
17H 00H 00H Audio Parameter (Memory 4) Load/rewrite audio parameter stored in Memory 4
18H 00H 00H Video Parameter (Memory 5) Load/rewrite video parameter stored in Memory 5
19H 00H 00H Audio Parameter (Memory 5) Load/rewrite audio parameter stored in Memory 5
1AH 00H 00H Video Parameter (Memory 6) Load/rewrite video parameter stored in Memory 6
1BH 00H 00H Audio Parameter (Memory 6) Load/rewrite audio parameter stored in Memory 6
1CH 00H 00H Video Parameter (Memory 7) Load/rewrite video parameter stored in Memory 7
1DH 00H 00H Audio Parameter (Memory 7) Load/rewrite audio parameter stored in Memory 7
1EH 00H 00H Video Parameter (Memory 8) Load/rewrite video parameter stored in Memory 8
1FH 00H 00H Audio Parameter (Memory 8) Load/rewrite audio parameter stored in Memory 8
: :
3EH 00H 00H Video Parameter (Memory 24) Load/rewrite video parameter stored in Memory 24
3FH 00H 00H Audio Parameter (Memory 24) Load/rewrite audio parameter stored in Memory 24
7 Preset Memory Name Area
xxH: 00H–17H (MEMORY 1–24)
Address Parameter Name Meaning of Value
60H xxH 00H NAME (0) Name of preset memory number xx (1st character)
60H xxH 01H NAME (1) Name of preset memory number xx (2nd character)
60H xxH 02H NAME (2) Name of preset memory number xx (3rd character)
60H xxH 03H NAME (3) Name of preset memory number xx (4th character)
60H xxH 04H NAME (4) Name of preset memory number xx (5th character)
60H xxH 05H NAME (5) Name of preset memory number xx (6th character)
60H xxH 06H NAME (6) Name of preset memory number xx (7th character)
60H xxH 07H NAME (7) Name of preset memory number xx (8th character)
