78
Menu List
11: PRESET MEMORY
Menu item Value
(Bold: default)
Explanation
LOAD 1: MEMORY1 –24: MEMORY24 (*5)
Selects the preset memory to load.
Pressing the [VALUE] knob lets you load the preset memory.
SAVE 1: MEMORY1 –24: MEMORY24 (*5)
Selects a preset memory for saving settings.
Pressing the [VALUE] knob lets you save the settings to the preset memory.
* The state of the [OUTPUT FADE] knob and [PHONES] knob (headphone
volume) is not saved in preset memory.
* The following settings menu are common to the unit (one set for the entire
unit), and therefore are not saved in preset memory.
5 PRESET MEMORY
5 MACRO
5 SEQUENCER
5 STILL IMAGE
5 FREEZE
5 AUTO SWITCHING
5 CTL/EXP
5 USB MEMORY
5 SYSTEM
INITIALIZE 1: MEMORY1 –24: MEMORY24 (*5)
Selects the preset memory to be initialized.
Press the [VALUE] knob to initialize the preset memory.
NAME EDIT 1: MEMORY1 –24: MEMORY24 (*5) Selects the preset memory to be renamed. Press the [VALUE] knob to edit the
name.
START UP
Specifies the settings loaded at startup.
LAST MEMORY
Restores the state that was in effect immediately before the power was turned
off (Last Memory function).
The current settings (Last Memory values) are saved every 4 seconds, and
when you exit a menu.
1: MEMORY1–24: MEMORY24 (*5) Recall the settings at the selected memory number.
MEMORY PROTECT OFF , ON
When this is “ON”, prohibits settings from being saved or initialized. This protects
the preset memories.
LOAD FROM USB MEMORY ENTER
Shows a list of the preset files (.V08preset) that are on the USB flash drive.
You can select a preset file and load the preset memory (1–24) into the unit.
SAVE TO USB MEMORY ENTER
Shows a list of the preset files (.V08preset) that are on the USB flash drive.
You can select the preset file used to overwrite the preset memory (1–24). If
you selected “NEW FILE...”, a new preset file is saved.
NUMBER OF MEMORY SW
When MEMORY is selected on the [MODE] button, this sets how many buttons function as memory selection buttons.
8 Preset memory 1–8: MEMORY [1]–[8] buttons
24
Preset memory 1–8: MEMORY [1]–[8] buttons
Preset memory 9–16: Cross-point A [1]–[8] buttons
Preset memory 17–24: Cross-point B [1]–[8] buttons
FADE TIME 0.0 –4.0sec Specifies the time of the transition when loading a preset memory.
MIX/WIPE OFF, ON
Switches the transition effect on/off.
PinP 1 OFF, ON
PinP 2 OFF, ON
DSK OFF, ON
LOAD PARAMETER Specifies the menu items that are applied when a preset memory is recalled.
VIDEO INPUT OFF, ON
Menu items for which this is “OFF” do not change when a preset memory is
recalled.
VIDEO OUTPUT OFF, ON
TRANSITION TIME OFF, ON
MIX/WIPE OFF, ON
SPLIT/VFX OFF, ON
PinP OFF, ON
DSK OFF, ON
VIDEO CROSSPOINT OFF, ON
VIDEO FADER INITIALIZE , ON
Switches whether to load the video fader position in a reset state (INITIALIZE)
or to reproduce its state when the preset memory was saved (ON).
AUDIO INPUT OFF, ON
Menu items for which this is “OFF” do not change when a preset memory is
recalled.
AUDIO OUTPUT OFF, ON
AUDIO FOLLOW OFF, ON
(*5) If you edited a preset memory’s name using “NAME EDIT”, the edited name is shown.
