39
Audio Operations
Silencing Only Specific Audio (Mute)
Here’s how to temporarily silence specific input audio or output audio (the mute function).
Muting input audio
1 .
Press the [MENU] button
0
”AUDIO INPUT”
0
select
“HDMI IN 1”–“HDMI IN 8” or “AUDIO IN”, and press
the [VALUE] knob.
2 .
Use the [VALUE] knob to select “INPUT MUTE”, and
press the [VALUE] knob.
3 .
Use the [VALUE] knob to select “ON”, and press the
[VALUE] knob.
4 .
Press the [MENU] button to quit the menu.
Muting output audio
1 .
Press the [MENU] button
0
”AUDIO OUTPUT”
0
“MASTER OUTPUT”
0
select “OUTPUT MUTE”, and
press the [VALUE] knob.
2 .
Use the [VALUE] knob to select “ON”, and press the
[VALUE] knob.
3 .
Press the [MENU] button to quit the menu.
Muting AUX-bus Audio
1 .
Press the [MENU] button
0
”AUDIO OUTPUT”
0
“AUX”
0
select “AUX MUTE”, and press the [VALUE]
knob.
2 .
Use the [VALUE] knob to select “ON”, and press the
[VALUE] knob.
3 .
Press the [MENU] button to quit the menu.
