68
Menu List
5: SPLIT/VFX
SPLIT/VFX A, B
Menu item Value
(Bold: default)
Explanation
SPLIT/VFX OFF , ON
Turns the split/visual effect on/off.
You can also use the SPLIT/VFX [A] or [B] button to turn this on/off.
SPLIT/VFX TYPE
SPLIT V , SPLIT H, PART MOSAIC,
BACKGROUND MOSAIC,
FULL MOSAIC, WAVE, RGB REPLACE,
COLORPASS, NEGATIVE, COLORIZE,
POSTERIZE, SILHOUETTE, EMBOSS,
FIND EDGES, MONOCOLOR,
HUE OFFSET, SATURATION OFFSET,
VALUE OFFSET
Specifies the split/visual effect types.
* The menu items differ for each split/visual effect.
9 SPLIT/VFX TYPE: SPLIT V Composites two videos split vertically at their centers.
Menu item Value (Bold: default) Explanation
A-CENTER -25.0– 0.0 –25.0%
Adjusts the horizontal position of the video shown on the left (A/PGM side).
You can adjust this by turning the SPLIT/VFX [A] knob.
B-CENTER -25.0– 0.0 –25.0%
Adjusts the horizontal position of the video shown on the right (B/PST side).
You can adjust this by turning the SPLIT/VFX [B] knob.
CENTER POSITION -50.0– 0.0 –50.0%
Adjusts the position of the boundary.
You can change the size of the two videos by shifting the boundary line.
You can adjust this by turning the SPLIT/VFX [A] or [B] knob while pressing it.
BORDER COLOR
WHITE , YELLOW, CYAN, GREEN,
MAGENTA, RED, BLUE, BLACK
Specifies the color of the border.
BORDER WIDTH 0– 3 –14 Adjusts the width of the border.
9 SPLIT/VFX TYPE: SPLIT H Composites two videos split horizontally at their centers.
Menu item Value (Bold: default) Explanation
A-CENTER -25.0– 0.0 –25.0%
Adjusts the vertical position of the video shown above (A/PGM side).
You can adjust this by turning the SPLIT/VFX [A] knob.
B-CENTER -25.0– 0.0 –25.0%
Adjusts the vertical position of the video shown above (B/PST side).
You can adjust this by turning the SPLIT/VFX [B] knob.
CENTER POSITION -50.0– 0.0 –50.0%
Adjusts the position of the boundary.
You can change the size of the two videos by shifting the boundary line.
You can adjust this by turning the SPLIT/VFX [A] or [B] knob while pressing it.
BORDER COLOR
WHITE , YELLOW, CYAN, GREEN,
MAGENTA, RED, BLUE, BLACK
Specifies the color of the border.
BORDER WIDTH 0– 3 –14 Adjusts the width of the border.
9 SPLIT/VFX TYPE: PART MOSAIC Applies a mosaic to the selected region.
Menu item Value
(Bold: default)
Explanation
POSITION H -100.0– 0.0 –100.0%
Adjusts the horizontal position of the selected area.
You can adjust this by turning the SPLIT/VFX [A] or [B] knob.
POSITION V -100.0– 0.0 –100.0%
Adjusts the vertical position of the selected area.
You can adjust this by turning the SPLIT/VFX [A] or [B] knob while pressing it.
AREA SIZE 10.0– 40.0 –100.0% Adjusts the size (zoom) of the selected area.
CORRECTION H -2000– 0 –2000 Adjusts the horizontal size of the selected area.
CORRECTION V -2000– 0 –2000 Adjusts the vertical size of the selected area.
BLOCK SIZE
OFF (1x1), 4x4, 8x8, 16x16, 32x32,
64x64 , 128x128, 256x256
Specifies the fineness (block size) of the mosaic.
MIX LEVEL 0– 255 Adjusts the intensity (output level) of the video with the visual effect applied.
