Video Operations
Background video
Inset screen 1
(PinP 1)
PinP 1
PinP 2
Inset screen 2
(PinP 2)
Here we explain the procedure for compositing video using “PinP
1”. You can also composite video using the same procedure using
“PinP 2”.
1 . Press a Cross-point A or B [1]–[8] button to select
the video you want to make the background video.
2 . Press the [MODE] button to select “PinP 1 SOURCE”.
3 . Press a PinP SOURCE [1]–[8] button to select the
video you want to make the inset screen.
4 . Press the PinP 1 [PVW] button to preview-output
the video of the inset screen.
The PinP 1 [PVW] button lights up in green and the inset screen
appears in the PVW section of the monitor, allowing you to check
the inset screen’s location and size.
At this stage, the final output has not yet been changed.
5 . Use the PinP 1 [POSITION H] and [POSITION V] knobs
to adjust the display position of the inset screen.
Knob Explanation
[POSITION H]
Adjusts the inset screen’s display position
horizontally.
Turn while pressing:
Adjusts the size of the inset screen.
[POSITION V]
Adjusts the inset screen’s display position
vertically.
Turn while pressing:
Adjusts the zoom of the video shown in the
inset screen.
6 . Press the PinP 1 [ON] button to turn on PinP
compositing (lit).
The PinP 1 [ON] button lights up in red, and the inset screen is
composited onto the background video and the result is sent to
final output.
7 . To turn off PinP compositing, press the PinP 1 [ON]
button once again.
MEMO
5 By long-pressing the PinP 1 (2) [PVW] button, you can access
the mode for selecting the inset screen without having to
press the [MODE] button and then select “PinP 1 SOURCE” or
“PinP 2 SOURCE”.
While pressing the PinP 1 (2) [PVW] button, press a PinP
SOURCE [1]–[8] button to select the video that you want to use
as the inset screen.
5 The fade time over which the inset screen appears or
disappears when you press the [ON] button is specified by the
setting of the TRANSITION TIME menu item “PinP 1 TIME” or
“PinP 2 TIME”.
5 By holding down the PinP 1 (PinP 2) [PVW] button and pressing
the [MENU] button, the PinP 1 or PinP 2 menu appears.
5 You can make PinP/DSK composition (p. 22) turn on/off in
tandem with the video transitions.
& “Turning PinP/DSK composition on/off in tandem with
video transitions” (p. 13)
After step 5, use the [AUTO] and [CUT] buttons or operate the
video fader to switch the video. PinP composition turns on, and
the composited result that is previewed is sent to final output.
Compositing Video with Picture-in-Picture (PinP)
Here’s how to composite an inset screen (a small separate screen) onto the background video.
You can use PinP 1 and PinP 2 simultaneously to composite two inset screens.
