Other Features
1 . Connect a footswitch as described in p. 5.
2 . Press the [MENU] button 0 “CTL/EXP” 0 “CTL/EXP 1”
or “CTL/EXP 2” 0 select “CTL/EXP TYPE”, and press
the [VALUE] knob.
3 . Use the [VALUE] knob to select “CTL A & CTL B”, and
press the [VALUE] knob.
4 . Use the [VALUE] knob to select CTL A or CTL B
“CATEGORY” and “VALUE”, and press the [VALUE] knob.
5 . Use the [VALUE] knob to select the function
that you want to assign to CTL A or CTL B of the
footswitch, and press the [VALUE] knob.
CATEGORY
Value Explanation
N/A No function is assigned.
PGM CH SELECT Switches the video sent to the A/PGM bus.
PST CH SELECT Switches the video sent to the B/PST bus.
AUX CH SELECT Switches the video sent to the AUX bus.
INPUT 1–8 ASSIGN
Each time you press the footswitch, the video
source of the specified input channel switches.
STILL OUTPUT
Pauses the normal output, and preview/final
outputs a cut of the still image.
PinP 1, 2 SOURCE Switches the video source of the inset screen.
DSK SOURCE Switches the DSK video source.
SW CONTROL
This works the same as when you press the
button selected in “VALUE”.
TAKE
Switches the video between A/PGM bus and
B/PST bus.
AUDIO INPUT MUTE
Turns the mute function on/off for the input
audio.
AUDIO OUTPUT MUTE
Turns the mute function on/off for the output
audio.
AUDIO INPUT SOLO
Turns the solo function on/off for the input
audio.
OUTPUT FADE
The same function as turning the [OUTPUT
FADE] knob.
Value Explanation
LOAD MEMORY Recalls a preset memory.
INPUT SCAN
Each time you press the footswitch, the INPUT
1–8 video changes in order.
MEMORY SCAN
Each time you press the footswitch, preset
memories 1–24 are recalled in order.
MACRO EXECUTE
Executes a macro (a series of recorded
operations).
SEQUENCER
MODE ON/OFF:
Turns sequencer function on/off.
NEXT:
When the sequencer function is on, the same
operation as when you press the [AUTO] button.
PREVIOUS:
When the sequencer function is on, the same
operation as when you press the [CUT] button.
AUTO SEQUENCE:
Turns the auto sequence function on/off.
VALUE
Configures the detailed settings related to “CATEGORY”.
6 . Press the [MENU] button to quit the menu.
Using a Footswitch
You can use a footswitch connected to the CTL/EXP 1, 2 jacks of the V-8HD to control the V-8HD with your foot.
You can assign various functions to the footswitch.
