3-56 T 1 A c c e s s R o u t e r
MAC Address MAC address of the Host to be reached.
Values: A 6-byte value
Default: 00-00-00-00-00-00
ARP Status Displays whether this ARP is enabled or disabled.
Values: Enable, Disable
Default: Enable
The ARP Details screen provides the following user-activated buttons:
Trusted Neighbor Table Screen
The Trusted Neighbors feature can be used to store RIP information only
from specific routers. This allows the router to reject any RIP information
coming from non-Trusted Neighbors. Only information coming from Trusted
Neighbors is kept by the router.
Access this menu by selecting Trusted Neighbors from the RIP Parameters on
the IP Gateway menu. This table is useful when the Network Administrator
wants to listen to RIP of specific router(s).
Figure 3.46 Trusted Neighbors Screen
Neighbor Details Screen
Access this screen (Figure 3.47) by clicking on the appropriate Index link. This
screen lists all the IP addresses of Trusted Neighbors.
Figure 3.47 Neighbor Details Screen
Button Function
Submit Sets any values that have been changed.
Static ARP Table Returns you to the previous screen.
Delete ARP Deletes this static ARP.
