– 137 –
Chapter 5 Shooting — Convenient shooting functions
Convenient shooting functions
Zebra patterns display
The camera can display two types of zebra patterns to the output image from the LCD monitor.
1
Select the [VIDEO OUT/LCD/VF] menu → [EI ASSIST] → [ZEBRA] → [ON].
f Select [MOMENT]. The zebra pattern is displayed for approximately five seconds when the the USER button to which [ZEBRA] is assigned is
pressed or the USER button icon is touched.
f Factory setting: [OFF]
Setting the detection level
1
Set each item in the [VIDEO OUT/LCD/VF] menu → [EI ASSIST].
Item Description of settings
[ZEBRA1 DETECT] Sets the detection level of zebra pattern 1.
[0%]…[109%]
(Factory setting: [80%])
[ZEBRA2 DETECT] Sets the detection level of zebra pattern 2.
[0%]…[109%]
(Factory setting: [100%])
[ZEBRA2] Enables/disables zebra pattern 2 and selects [SPOT].
[ON], [SPOT], [OFF]
(Factory setting: [OFF])
r Display area of the zebra pattern
The display area of the zebra pattern varies depending on the [VIDEO OUT/LCD/VF] menu → [EI ASSIST] setting.
When [SPOT] is selected in [ZEBRA2], the area corresponding to the [ZEBRA1 DETECT] setting value to the [ZEBRA2 DETECT] setting value is
displayed in zebra pattern.
[ZEBRA2]
[ON] [OFF] [SPOT]
[109%]
[ZEBRA2 DETECT]
[ZEBRA1 DETECT]
[0%]
@ @ NOTE
t The zebra pattern cannot be recorded.
t The zebra pattern is not displayed while displaying the color bars.
The zebra pattern is not displayed when the [SCENE FILE] menu
→ [GAMMA MODE SEL] → [HLG] is selected.
Displaying the center marker
A center marker can be displayed.
1
Select the type of the center marker in the [VIDEO OUT/LCD/VF] menu → [MARKER] → [CENTER MARKER].
f The center marker is not displayed when [OFF] is selected.
