– 98 –
Chapter 4 Operation — Menu settings
The camera title set here is also displayed as the individual device name in the NDI | HX compatible switcher.
(Factory setting: [AG-CX350]/[AJ-UPX360])
[SYSTEM] menu
Configure the settings regarding the recording format of video and audio.
[FREQUENCY]
Sets the system frequency.
The items that can be set are as follows.
f [59.94Hz], [50.00Hz]
(Factory setting: [59.94Hz] (when [AREA SETTINGS] is set to [AREA 1], [AREA 2], or [AREA 3]), [50.00Hz] (when [AREA SETTINGS] is set to [AREA
4]))
@ @ NOTE
t The camera will restart when the setting is changed.
[FILE FORMAT]
Sets the file format for recording.
[P2] Sets to record in the MXF file format of P2 format.
[MOV] Sets to record in the MOV file format of MOV format.
[AVCHD] Sets to record in the MTS file format of AVCHD format.
(Factory setting: [MOV])
[REC FORMAT]
Sets the signal format and codec mode for recording.
f When [FREQUENCY] is set to [50.00Hz], and [FILE FORMAT] is set to [P2]
The items that can be set are as follows.
- [1080-50.00p/AVC-I422], [1080-50.00p/AVC-G25], [1080-50.00p/AVC-G12], [1080-50.00i/AVC-G50], [1080-50.00i/AVC-G25], [1080-50.00i/
AVC-G12], [720-50.00p/AVC-G50], [720-50.00p/AVC-G25], [720-50.00p/AVC-G12]
f When [FREQUENCY] is set to [50.00Hz], and [FILE FORMAT] is set to [MOV]
The items that can be set are as follows.
- [2160-50.00p/420LongGOP 150M], [2160-50.00p/HEVC LongGOP 200M], [2160-50.00p/HEVC LongGOP 100M], [2160-25.00p/420LongGOP
100M], [2160-25.00p/HEVC LongGOP 150M], [2160-25.00p/422LongGOP 150M], [2160-25.00p/422ALL-I 400M], [1080-50.00p/422LongGOP
100M], [1080-50.00p/422ALL-I 200M], [1080-50.00i/422LongGOP 50M], [1080-50.00i/422ALL-I 100M], [1080-25.00p/422LongGOP 50M],
[1080-25.00p/422ALL-I 100M]
(Factory setting: [1080-50.00i/422ALL-I 100M])
f When [FREQUENCY] is [50.00Hz] and [FILE FORMAT] is [AVCHD]
The items that can be set are as follows.
- [1080-50.00p/AVCHD PS], [1080-50.00i/AVCHD PH], [1080-50.00i/AVCHD HA], [720-50.00p/AVCHD PM], [576-50.00i/AVCHD SA]
(Factory setting: [1080-50.00i/AVCHD PH])
f When [FREQUENCY] is set to [59.94Hz], and [FILE FORMAT] is set to [P2]
The items that can be set are as follows.
- [1080-59.94p/AVC-I422], [1080-59.94p/AVC-G25], [1080-59.94p/AVC-G12], [1080-59.94i/AVC-G50], [1080-59.94i/AVC-G25], [1080-59.94i/
AVC-G12], [720-59.94p/AVC-G50], [720-59.94p/AVC-G25], [720-59.94p/AVC-G12]
f When [FREQUENCY] is set to [59.94Hz], and [FILE FORMAT] is set to [MOV]
The items that can be set are as follows.
- [2160-59.94p/420LongGOP 150M], [2160-59.94p/HEVC LongGOP 200M], [2160-50.00p/HEVC LongGOP 100M], [2160-29.97p/420LongGOP
100M], [2160-29.97p/HEVC LongGOP 150M], [2160-29.97p/422LongGOP 150M], [2160-29.97p/422ALL-I 400M], [2160-23.98p/420LongGOP
100M], [2160-23.98p/HEVC LongGOP 150M], [2160-23.98p/422LongGOP 150M], [2160-23.98p/422ALL-I 400M], [1080-59.94p/422LongGOP
100M], [1080-59.94p/422ALL-I 200M], [1080-59.94i/422LongGOP 50M], [1080-59.94i/422ALL-I 100M], [1080-29.97p/422LongGOP 50M],
[1080-29.97p/422ALL-I 100M], [1080-23.98p/422LongGOP 50M], [1080-23.98p/422ALL-I 100M]
(Factory setting: [1080-59.94i/422ALL-I 100M])
f When [FREQUENCY] is [59.94Hz] and [FILE FORMAT] is [AVCHD]
The items that can be set are as follows.
- [1080-59.94p/AVCHD PS], [1080-59.94i/AVCHD PH], [1080-59.94i/AVCHD HA], [1080-23.98p/AVCHD PH], [720-59.94p/AVCHD PM], [480-59.94i/
AVCHD SA]
(Factory setting: [1080-59.94i/AVCHD PH])
[ASPECT]
Sets the aspect ratio of the video to record in the SD signal format (480i and 576i).
[4:3] Records using standard 4:3 mode. Cut both the left and right edges.
[16:9] Camera images are compressed in the horizontal direction when recording. Replaying recorded images on a TV monitor that
supports a wide screen will convert the images to an aspect ratio of 16:9.
(Factory setting: [4:3])
