– 206 –
Chapter 11 Specification — Specifications
Audio input/output
Built-in microphone Supports stereo microphone
<AUDIO INPUT 1>/<AUDIO INPUT 2> terminal XLR × 2, 3-pin
Input high impedance, <LINE>/<MIC>/< + 48V> (switch selection)
f <LINE>:
4 dBu/0 dBu (menu selection)
f <MIC>:
− 40 dBu/ − 50 dBu/ − 60 dBu (menu selection)
<SDI OUT> terminal LPCM 4ch
<HDMI> terminal LPCM 2ch
<AV OUT> terminal 3.5 mm diameter mini jack
Output level: 600 Ω , 316 mV
Headphone terminal 3.5 mm diameter stereo mini jack × 1
Speaker 20 mm diameter, round × 1
Other input/output
<TC IN/OUT> terminal BNC × 1
Used as input/output terminal, input/output switch by menu
f Input: 1.0 V – 4.0 V [p-p], 10 k Ω
f Output: 2.0 V±0.5 V [p-p], low impedance
<REMOTE> terminal 2.5 mm diameter super mini jack × 1
<USB2.0 HOST> terminal Type A connector, 4-pin (5 V, 0.5 A), for attaching the wireless module (optional)
<USB3.0 DEVICE> terminal USB 3.1 GEN1 type C connector, with USB mass storage function, without USB bus-powered function
<LAN> terminal RJ-45: 1000BASE-T/100BASE-TX/10BASE-T
<DC IN 12V> terminal DC12 V, EIAJ type 4
Monitor
LCD monitor 3.2-inch TFT LCD (3:2): Approx. 1620000 dots, touch panel compatible
Video display area (16:9): Approx. 1370000 dots
Viewfinder 0.39-inch OLED (organic EL display) (4:3): Approx. 2360000 dots
Video display area (16:9): Approx. 1770000 dots
AC adaptor
Power source
AC d 100 V – 240 V, 50 Hz/60 Hz, 1.2 A
Power output
DC e 12 V, 3.0 A
indicates safety information.
Operating ambient temperature 0 °C – 40 °C (32 °F – 104 °F)
Operating ambient humidity 10% – 90% (relative humidity, no condensation)
Mass Approx. 225 ] (0.496 lbs.)
Dimensions (W × H × D) 115 mm × 37 mm × 57 mm (4-1/2 inches × 1-7/16 inches × 2-1/4 inches) (excluding the DC cable section)
Battery charger (AG-BRD50)
Input voltage
DC e 12 V, 3.0 A
Output voltage
DC e 8.4 V, 4.0 A
indicates safety information.
Charging current Maximum 4000 mA
Operating ambient humidity 10% – 80% (relative humidity, no condensation)
Mass Approx. 230 ] (0.507 lbs.)
Dimensions (W × H × D) 130 mm × 48 mm × 107 mm (5-1/8 inches × 1-7/8 inches × 4-3/16 inches)
Battery pack (AG-VBR59)
Voltage/capacity
DC e 7.28 V/5900 mAh 43 Wh
indicates safety information.
