– 203 –
Chapter 11 Specification — Specifications
Specifications
General
Power
DC e 7.28 V (when battery is used)
DC e 12 V (when the AC adaptor is used)
Power consumption
17 W (when the LCD monitor is used)
indicates safety information.
Operating ambient temperature 0 °C – 40 °C (32 °F – 104 °F)
Operating ambient humidity 10% – 80% (relative humidity, no condensation)
Mass Approx. 1.9 k ] (4.19 lbs.) (body only, excluding lens hood, battery, and accessories)
Approx. 2.3 k ] (5.07 lbs.) (including lens hood, battery, and accessories of microphone holder)
Dimensions (W × H × D) Camera (including lens hood)
180 mm × 173 mm × 311 mm
(7-3/32 inches × 6-13/16 inches × 12-1/4 inches)
(excluding eye cup and protrusion)
Camera unit
Pickup device 1.0-inch MOS solid state image sensor
Number of pixels Number of effective pixels: Approx. 15.03 million pixels
Lens Optical image stabilizer lens, motorized 20x zoom
F2.8 – F4.5 (f=8.8 mm – 176 mm)
35 mm conversion: 24.5 mm – 490 mm (16:9)
Filter diameter 67 mm
Optical filter f ND filter
<CLR>, <1/4>, <1/16>, <1/64>
f IR cut filter
[ON]/[OFF] by assigning [IR REC] to the USER button (switched by menu)
Minimum object distance (M.O.D) 10 cm (wide angle) from the lens
1.0 m (telephoto angle) from the lens
Color temperature setting ATW, ATW LOCK, Ach, Bch, preset 3200 K/preset 5600 K/VAR (2000 K – 15000 K)
Gain setting <L>/<M>/<H> selector switch
− 3 dB – 18 dB (1 dB step)
(When assigning [S.GAIN] to the USER button: Switching between 24 dB, 30 dB, and 36 dB)
Shutter speed When the [SYSTEM] menu → [FREQUENCY] → [59.94Hz] is set
f 59.94i/59.94p mode:
1/60 sec. (shutter off), 1/100 sec., 1/120 sec., 1/250 sec., 1/500 sec., 1/1000 sec., 1/2000 sec., 1/4000
sec., 1/8000 sec., 1/10000 sec.
f 29.97p mode:
1/30 sec., 1/50 sec. (shutter off), 1/60 sec., 1/100 sec., 1/120 sec., 1/250 sec., 1/500 sec., 1/1000 sec.,
1/2000 sec., 1/4000 sec., 1/8000 sec., 1/10000 sec.
f 23.98p mode:
1/24 sec., 1/48 sec., 1/50 sec. (shutter off), 1/60 sec., 1/100 sec., 1/120 sec., 1/250 sec., 1/500 sec.,
1/1000 sec., 1/2000 sec., 1/4000 sec., 1/8000 sec., 1/10000 sec.
When the [SYSTEM] menu → [FREQUENCY] → [50.00Hz] is set
f 50i/50p mode:
1/50 sec. (shutter off), 1/60 sec., 1/100 sec., 1/120 sec., 1/250 sec., 1/500 sec., 1/1000 sec., 1/2000 sec.,
1/4000 sec., 1/8000 sec., 1/10000 sec.
f 25p mode:
1/25 sec., 1/50 sec. (shutter off), 1/60 sec., 1/100 sec., 1/120 sec., 1/250 sec., 1/500 sec., 1/1000 sec.,
1/2000 sec., 1/4000 sec., 1/8000 sec., 1/10000 sec.
Slow shutter speed When the [SYSTEM] menu → [FREQUENCY] → [59.94Hz] is set
f 59.94i/59.94p mode:
1/1 sec., 1/2 sec., 1/4 sec., 1/6 sec., 1/15 sec., 1/30 sec.
f 29.97p mode:
1/1 sec., 1/2 sec., 1/4 sec., 1/6 sec., 1/15 sec.
f 23.98p mode:
1/1 sec., 1/2 sec., 1/4 sec., 1/6 sec., 1/12 sec.
When the [SYSTEM] menu → [FREQUENCY] → [50.00Hz] is set
f 50i/50p mode:
1/1 sec., 1/2 sec., 1/4 sec., 1/6 sec., 1/12 sec., 1/25 sec.
f 25p mode:
1/1 sec., 1/2 sec., 1/4 sec., 1/6 sec., 1/12 sec.
