– 158 –
Chapter 7 Output and Screen Display — Output format
Output format
The format to be output differs depending on the setting in the [SYSTEM] menu → [FREQUENCY]/[REC FORMAT].
Format that can be output from the <SDI OUT> terminal
The format that can be output from the <SDI OUT> terminal differs with following combination of the settings.
f [SYSTEM] menu → [FREQUENCY]
f [SYSTEM] menu → [REC FORMAT]
f [VIDEO OUT/LCD/VF] menu → [SDI OUT] → [OUT FORMAT]
Item
Output Format
[OUT FORMAT] [FREQUENCY]
[REC FORMAT]
Resolution Frequency
[59.94Hz] 3840 × 2160 59.94p 1920 × 1080 59.94p
1920 × 1080 59.94i (Factory setting)
29.97p 1920 × 1080 29.97PsF
23.98p 1920 × 1080 23.98PsF
1920 × 1080 59.94p 1920 × 1080 59.94p
1920 × 1080 59.94i (Factory setting)
720 × 480 59.94i
59.94i 1920 × 1080 59.94i (Factory setting)
720 × 480 59.94i
29.97p 1920 × 1080 29.97p (Factory setting)
720 × 480 59.94i
23.98p 1920 × 1080 23.98p (Factory setting)
720 × 480 59.94i
1280 × 720 59.94p 1280 × 720 59.94p (Factory setting)
720 × 480 59.94i
720 × 480 59.94i 720 × 480 59.94i
[50.00Hz] 3840 × 2160 50.00p 1920 × 1080 50.00p
1920 × 1080 50.00i (Factory setting)
25.00p 1920 × 1080 25.00PsF
1920 × 1080 50.00p 1920 × 1080 50.00p
1920 × 1080 50.00i (Factory setting)
720 × 576 50.00i
50.00i 1920 × 1080 50.00i (Factory setting)
720 × 576 50.00i
25.00p 1920 × 1080 25.00PsF (Factory setting)
720 × 576 50.00i
1280 × 720 50.00p 1280 × 720 50.00p (Factory setting)
720 × 576 50.00i
720 × 576 50.00i 720 × 576 50.00i
@ @ NOTE
t The 3840 × 2160 output is not supported.
t [OUT FORMAT] restores the factory settings when the settings of [FREQUENCY] and [REC FORMAT] change and the current setting values of [OUT
FORMAT] cannot be acquired.
t The output format when playing back from the thumbnail screen is as follows.
‑ It will be the value set in [OUT FORMAT] when the recording resolution of the playback clip is the same as [REC FORMAT].
‑ It will be factory setting of [OUT FORMAT] when the recording resolution of the playback clip is different from [REC FORMAT].
Format that can be output from the <HDMI> terminal
The format that can be output from the <HDMI> terminal differs with following combination of the settings.
f [SYSTEM] menu → [FREQUENCY]
f [SYSTEM] menu → [REC FORMAT]
f [VIDEO OUT/LCD/VF] menu → [HDMI OUT] → [OUT FORMAT]
Item
Output format
[OUT FORMAT] [FREQUENCY]
[REC FORMAT]
Resolution Frequency
[59.94Hz] 3840 × 2160 59.94p 3840 × 2160 59.94p
3840 × 2160 59.94p (4:2:0/8-bit)
1920 × 1080 59.94p (Factory setting)
1920 × 1080 59.94i
29.97p 3840 × 2160 29.97p
1920 × 1080 29.97p (Factory setting)
23.98p 3840 × 2160 23.98p
1920 × 1080 23.98p (Factory setting)
1920 × 1080 59.94p 1920 × 1080 59.94p (Factory setting)
1920 × 1080 59.94i
