– 51 –
Chapter 3 Preparation — Setting of time data
Cautions when switching the power supply from the battery to the AC adaptor while an external lock is active
To maintain the continuity of the time code generator power, remove the battery only after the power status display in the camera image screen has
changed to after connecting the AC adaptor to the <DC IN 12V> terminal. The continuity of the external lock of the time code is not guaranteed
when the battery is removed first.
Supplying the time code externally
The time code output from the camera corresponding to the camera video or the playback video can be supplied to an external recording device.
<TC IN/OUT> terminal
<SDI OUT> terminal
SDI IN terminal
TC IN terminal
VTR, etc.
1
Select the [RECORDING] menu → [TC/UB] → [TC IN/OUT SEL] → [TC OUT].
2
Select the [RECORDING] menu → [TC/UB] → [TC OUT REF] → [RECORDING].
The same time code can be recorded to the video of the same time on two devices.
r To match the time code output from the <TC IN/OUT> terminal to the video of the SDI output or the monitor output
1
Select the [RECORDING] menu → [TC/UB] → [TC OUT REF] → [SDI OUT].
@ @ NOTE
t TCR is output during playback. TCG output during playback is not supported.
t The time code output may shift by 1 frame when the recording frame frequency of [REC FORMAT] is set to 23.98p.
t External locks by user bits are not supported.
