– 81 –
Chapter 4 Operation — Menu settings
[CH3]
Outputs the signal for audio channel 3 as monaural. When [FILE FORMAT] is set to [AVCHD], it will operate in [CH1].
[CH4]
Outputs the signal for audio channel 4 as monaural. When [FILE FORMAT] is set to [AVCHD], it will operate in [CH2].
[CH3/4 STEREO]
Outputs the signals of the audio channel 3 and the audio channel 4 as stereo. Outputs as monaural from the built-in speaker.
When [FILE FORMAT] is set to [AVCHD], it will operate in [CH1/2 STEREO].
[CH3/4 MIX]
Mixes the signals of the audio channel 3 and the audio channel 4 and outputs as monaural. When [FILE FORMAT] is set to
[AVCHD], it will operate in [CH1/2 MIX].
(Factory setting: [CH1/2 STEREO])
[ALARM]
[BATTERY END]
Sets whether to sound the alarm when the remaining battery level is exhausted.
The items that can be set are as follows.
f
[HIGH], [MED], [LOW], [OFF]
(Factory setting: [OFF])
[MEDIA END]
Sets whether to sound the alarm when the remaining recording capacity of the memory card is exhausted.
The items that can be set are as follows.
f
[HIGH], [MED], [LOW], [OFF]
(Factory setting: [OFF])
[WARNING]
Sets whether to sound the alarm when a system error or warning occurs.
The items that can be set are as follows.
f
[HIGH], [MED], [LOW], [OFF]
(Factory setting: [OFF])
[VIDEO OUT/LCD/VF] menu
Configures the settings for the external output, the information to display in the LCD monitor or viewfinder and the output format.
[VIDEO OUT SEL]
Switches the external output destination of the audio file.
[SDI
+
HDMI]
Outputs from the <SDI OUT> terminal and the <HDMI> terminal.
[AV
+
HDMI]
Outputs from the <AV OUT> terminal and the <HDMI> terminal.
(Factory setting: [SDI
+
HDMI])
[SDI OUT]
[OUTPUT SW]
Enables/disables the output from the <SDI OUT> terminal.
[ON]
Outputs the video.
[OFF]
Does not output the video.
(Factory setting: [ON])
[OUT FORMAT]
Selects the signal to output from the <SDI OUT> terminal. The items that can be selected differ depending on the [SYSTEM] menu
→
[FREQUENCY]/
[FILE FORMAT]/[REC FORMAT] setting.
[1920
×
1080p]
Outputs in 1920
×
1080p.
[1920
×
1080i]
Outputs in 1920
×
1080i.
[1920
×
1080PsF]
Outputs in 1920
×
1080PsF.
[1280
×
720p]
Outputs in 1280
×
720p.
[720
×
480i]
Outputs in 720
×
480i.
[720
×
576i]
Outputs in 720
×
576i.
(Factory setting: [1920
×
1080i])
@
@
NOTE
t
[3G-SDI OUT]
Sets the format of the 3G SDI signal output from the <SDI OUT> terminal. Can be set when the 3G SDI signal is output.
[LEVEL‑A]
Selects the LEVEL-A method.
[LEVEL‑B]
Selects the LEVEL-B DL method.
(Factory setting: [LEVEL-B])
