Panasonic AG-CX350 4K Camcorder - Manual (Page 189)

– 189 –
Chapter 9 Network Connection — NDI|HX function
Enabling the NDI | HX function
Perform the setting for the NDI | HX function, and then enable the NDI | HX function referring to the information in the NewTek website, etc. [NDI | HX] is
displayed in the [NETWORK] menu → [NDI | HX] → [ACTIVATION] when the NDI | HX function is enabled.
@ @ NOTE
t The NDI | HX function will remain enabled once it has been set, unless the activation information saved on the camera is deleted.
t To enable the NDI | HX function of the camera using the tool from NewTek, it is necessary to select [NDI | HX] in the [NETWORK] menu → [NETWORK
FUNC].
Streaming with multicast
One streaming can be distributed to multiple NDI | HX compatible switchers via supported router, etc., when the multicast function is used.
1
Select the [NETWORK] menu → [NDI | HX] → [MULTICAST] → [ENABLE].
2
Select the [NETWORK] menu → [NDI | HX], and specify [MULTICAST ADDRESS] and [MULTICAST PORT].
f Set [MULTICAST ADDRESS] within following range.
IPv4: 224.0.1.0 to 239.255.255.254
IPv6: Multicast address starting with FF
f Set [MULTICAST PORT] within the range of 1024 to 50000.
@ @ NOTE
t One that has added + 1 to the end of the specified multicast address is also used for NDI | HX.
t Disable the LAN card not to be used when receiving the multicast video to be displayed on a computer with multiple LAN cards installed.
Using the NDI | HX function
Control the camera by operating the NDI | HX compatible switcher.
@ @ NOTE
t Streaming may stop when the date/time is set while streaming.
Disabling the NDI | HX function
1
Select the [NETWORK] menu → [NDI | HX] → [CLEAR ACTIVATION].
The activation information saved to the camera is deleted.
After the activation information is deleted, the NDI
| HX function cannot be used until the NDI | HX function is enabled again.
