Panasonic AG-CX350 4K Camcorder User Manual
Page 148
– 148 –
Chapter 6 Playback — Thumbnail operation
6
Displaying the connection status of the wired LAN/wireless LAN
Displays the connection status of the wired LAN and wireless LAN.
(No display): It is not connected to the wired LAN or wireless LAN. It is set to the [NETWORK] menu
→
[DEVICE SEL]
→
[OFF].
: A status where the wired LAN is set and ROP is not connected.
: A status where the wired LAN is set and ROP is connected.
: A status where the wireless LAN is set and ROP is not connected.
: A status where the wireless LAN is set and ROP is connected.
7 Power status display
: Displays the remaining battery level while powered with the battery.
: Displayed when powered with the AC adaptor.
8 Cursor
9 Clip that cannot be played back
Displays when the clip cannot be played back in the camera such as standard violation.
10 Page switching button
Switches the page of the thumbnail screen.
[
`
]:
Moves to previous page
[
{
]:
Moves to next page
11 Scroll bar
Indicates which part of the whole thumbnail is currently being viewed.
@
@
NOTE
t
When P2 is selected as the recording file format, a clip recorded over multiple memory cards is displayed as one clip.
Display of the clips in the thumbnail screen
2
7
1
8
9
3
4
6
5
11
10
1 Thumbnail number
Displays the thumbnail number in [0001] to [9999].
Normally, the number assigned to the clip in the order of recording is displayed.
2 Resume play status
3 Number of recording pixels, system frequency
4
Recording file format, recording codec
5
Protection status of the clip
This is displayed when the clip is protected.
6
Standard time code/clip name
The first eight digits for the time code when starting shooting of a clip or the file name of the clip are displayed in alphanumeric.
The information to display is set in the [THUMBNAIL] menu
→
[DISPLAY]
→
[DATA].
7 Delete selection status
8 Clip that cannot be played back
This is displayed when the clip cannot be played back with the camera because the system frequency is different, etc.
9 Copy selection status
This is displayed when the clip is selected.
10 Defective clip/unknown clip
: This is displayed for a defective P2 clip that may be repaired.
: This is displayed for a defective P2 clip that cannot be repaired.
: This is displayed for a P2 clip with a different format for P2 standard.
11 Incomplete clip
: This is displayed for a P2 clip when the clip is recorded over multiple memory cards, and any of those memory cards are not inserted.
