– 161 –
Chapter 7 Output and Screen Display — Screen status display
f
[!SDXC]:
The SDXC memory card is not inserted for MOV recording
f
(No display):
It is in one of the following conditions.
-
A memory card has not been inserted.
-
The memory card cannot be recognized.
-
The [NETWORK] menu
→
[NETWORK FUNC]
→
[NDI
|
HX] is set.
7 External equipment recording operation control status (<SDI OUT>/<HDMI> terminal)
Displays the control status of the recording start and recording stop on the external equipment connected to the <SDI OUT> terminal and the
<HDMI> terminal.
f
[
S/H]:
Recording instruction is output to the output from the <SDI OUT> terminal and <HDMI> terminal.
f
[S/H]:
Pause instruction is output to the output from the <SDI OUT> terminal and <HDMI> terminal.
f
[ SDI]:
Recording instruction is output to the output from the <SDI OUT> terminal.
f
[SDI]:
Pause instruction is output to the output from the <SDI OUT> terminal.
f
[ HDMI]:
Recording instruction is output to the output from the <HDMI> terminal.
f
[HDMI]:
Pause instruction is output to the output from the <HDMI> terminal.
8 Recording status (card slot 2)
Displays the recording status of the memory card in card slot 2.
f
:
Not target for recording.
f
(flashing):
Recognizing the memory card.
f
:
The recording is stopped while the recording target memory card is inserted.
f
:
Recording.
f
(Flashing red dot):
Processing to stop the recording.
f
[P ]:
Recording is stopped with pre-recording is enabled and the recording target memory card is inserted.
f
(No display):
It is in one of the following conditions.
-
A memory card has not been inserted.
-
The memory card cannot be recognized.
-
The [NETWORK] menu
→
[NETWORK FUNC]
→
[NDI
|
HX] is set.
9 Remaining recording capacity and status of the memory card (card slot 2)
Displays the remaining recording capacity and status of the memory card in card slot 2.
f
[0min] to [999min]:
Remaining recording capacity (999 minutes or more is displayed as [999min])
-
The display will flash when the remaining recording capacity becomes two minutes or less.
-
The recording capacity available for simultaneous recording (recording capacity for the memory card of the two memory cards with less recording
capacity) is displayed when simultaneous recording is performed.
f
[WP]:
Write protected (the write protection switch of the memory card is set to the LOCK side)
f
[END]:
No remaining recording capacity (no remaining recording capacity on the memory card)
f
[ERR]:
A memory card that cannot record is inserted (the card is recognized but cannot record due to a format error, a card other than a memory
card being inserted, etc.)
f
[!SDXC]:
The SDXC memory card is not inserted for MOV recording
f
(No display):
It is in one of the following conditions.
-
A memory card has not been inserted.
-
The memory card cannot be recognized.
-
The [NETWORK] menu
→
[NETWORK FUNC]
→
[NDI
|
HX] is set.
10 Special recording function
Displays the status of special recording function.
f
[INTRVL]:
The interval recording is stopped.
f
[I-REC]:
The interval recording is in progress. (Displayed in red)
11 Two-slot function
Displays the setting status of the recording function using two memory cards.
It is displayed with a slanted line if it is in a condition that cannot perform two-slot recording even if each function is enabled.
f
[RELAY]:
When the relay recording is enabled
f
[SIMUL]:
When the simultaneous recording is enabled
f
[BACKGR]:
When the background recording is enabled
f
(No display):
During standard recording (when set to the [NETWORK] menu
→
[NETWORK FUNC]
→
[NDI
|
HX], [NDI
|
HX] is displayed)
12 Flash band compensation function
f
[FBC]:
Displayed when the flash band compensation function is operating.
13 Streaming status
Displays the streaming status.
f
:
When the camera is connected to a device to receive the streaming video, and the streaming video is distributed
f
(flashing):
When the camera is being connected to a device to receive the streaming video
f
:
When the streaming function is enabled, it is in condition to operate properly, and the streaming video is not distributed
f
:
When there is an error in the streaming function and cannot operate
f
(No display):
When the streaming function is disabled
14 High dynamic range recording function/dynamic range stretcher function
f
[HDR]:
When set to the [SCENE FILE] menu
→
[GAMMA MODE SEL]
→
[HLG]
f
[DRS]:
When the dynamic range stretcher function is operating
15 Connection status of the wireless LAN/wired LAN
Displays the connection status of the wireless LAN or wired LAN.
f
:
When set to the wireless LAN and the ROP is not connected
