– 82 –
Chapter 4 Operation — Menu settings
[SD-SDI EDH]
Sets whether to superimpose EDH when output from the <SDI OUT> terminal is the SD signal (480i and 576i).
[ON] Superimposes.
[OFF] Does not superimpose.
(Factory setting: [ON])
[SDI REC REMOTE]
Sets if the recording operation against the external equipment connected to the <SDI OUT> terminal (such as recorder) is to be controlled or not.
[ON] Controls the recording operation of the external equipment.
[OFF] Does not control the recording operation of the external equipment.
(Factory setting: [OFF])
@ @ NOTE
t This cannot be set when the [RECORDING] menu → [REC FUNCTION] → [REC MODE] is set to [INTERVAL].
[SDI OUT CHAR]
Sets whether to superimpose the character to the output from the <SDI OUT> terminal.
[ON] Superimposes.
[OFF] Does not superimpose.
(Factory setting: [OFF])
[SDI OUT ZEBRA]
Sets whether to superimpose the zebra signal to the output from the <SDI OUT> terminal. The settings of the zebra signal follow the zebra signal
settings in the [VIDEO OUT/LCD/VF] menu
→ [EI ASSIST].
[ON] Superimposes.
[OFF] Does not superimpose.
(Factory setting: [OFF])
[SDI OUT HDR]
Sets the output image from the <SDI OUT> terminal.
[SDR] Outputs in the standard dynamic range.
[HDR] Outputs in the high dynamic range.
(Factory setting: [HDR])
@ @ NOTE
t The setting is fixed to [SDR] when set to following menu.
‑ [SYSTEM] menu → [REC FORMAT] → [480-59.94i/AVCHD SA]
‑ [SYSTEM] menu → [REC FORMAT] → [576-50.00i/AVCHD SA]
‑ [VIDEO OUT/LCD/VF] menu → [SDI OUT] → [OUT FORMAT] → [720 × 480i]
‑ [VIDEO OUT/LCD/VF] menu → [SDI OUT] → [OUT FORMAT] → [720 × 576i]
t When the [SCENE FILE] menu → [GAMMA MODE SEL] is set to anything other than [HLG], the camera image is output in the standard dynamic
range.
[HDMI OUT]
[OUT FORMAT]
Selects the signal to output from the <HDMI> terminal. The items that can be selected differ depending on the [SYSTEM] menu → [FREQUENCY]/[FILE
FORMAT]/[REC FORMAT] setting.
[3840 × 2160p] Outputs in 3840 × 2160p (4:2:2/10-bit).
[3840 × 2160p(420/8bit)] Outputs in 3840 × 2160p (4:2:0/8-bit).
[1920 × 1080p] Outputs in 1920 × 1080p.
[1920 × 1080i] Outputs in 1920 × 1080i.
[1280 × 720p] Outputs in 1280 × 720p.
[720 × 480p] Outputs in 720 × 480p.
[720 × 576p] Outputs in 720 × 576p.
(Factory setting: [1920 × 1080p])
@ @ NOTE
t For the combinations that can be set, refer to “Format that can be output from the <HDMI> terminal” (page 158).
[HDMI TC OUT]
Sets if the time code information is output or not in the output from the <HDMI> terminal.
The items that can be set are as follows.
f [ON], [OFF]
