Panasonic AG-CX350 4K Camcorder - Manual (Page 94)

– 94 –
Chapter 4 Operation — Menu settings
- [1280 × 720-60fps 14M], [1280 × 720-60fps 8M], [1280 × 720-60fps 3M], [640 × 360-30fps 4M], [640 × 360-30fps 1.5M], [640 × 360-30fps 0.7M],
[320 × 180-30fps 4M], [320 × 180-30fps 1.5M], [320 × 180-30fps 0.5M]
(Factory setting: [640 × 360-30fps 0.7M])
@ @ NOTE
t Cannot be set when [FILE FORMAT] is set to [AVCHD] or [REC FORMAT] is set to UHD.
[START TRIGGER]
Sets whether to start streaming with operation of the camera or operation of the application software.
The items that can be set are as follows.
f [CAMERA], [RECEIVER], [RECEIVER(MULTICAST)]
(Factory setting: [RECEIVER])
[CONNECTION INFO.]
Selects the internal memory of the camera or the memory card as the reference location for the transfer destination when starting a stream with the
operation of the camera.
The items that can be set are as follows.
f [MEMORY], [SD CARD]
(Factory setting: [MEMORY])
[DATA TYPE]
Displays the type of the setting data. (Cannot be changed)
[GENERAL] General streaming settings
[P2CAST] P2 Cast setting
[RECEIVER URL]
Enter the destination URL in following format.
f rtmp://(server URL):(port number)/(path)/(stream key)
f rtmps://(server URL):(port number)/(path)/(stream key)
[MULTICAST ADDRESS]
Sets the address when using the streaming with the multicast.
(Factory setting: [239.192.0.20])
[MULTICAST PORT]
Sets the port number when using the streaming with the multicast.
(Factory setting: [37004])
[LOAD (SD CARD)]
Loads the settings file from the memory card and reflects in the menu when [CONNECTION INFO.] is set to [MEMORY].
The items that can be selected are as follows.
f [YES], [NO]
[SAVE (SD CARD)]
Encrypts and saves the information of the destination URL to the memory card.
The items that can be selected are as follows.
f [YES], [NO]
[CLEAR (MEMORY)]
Clears the contents of the streaming setting set in the menu item.
The P2 Cast setting information is also cleared.
[START]
Starts streaming.
The items that can be set are as follows.
f [ON], [OFF]
(Factory setting: [OFF])
[NDI | HX]
Performs settings related to NDI | HX.
[ACTIVATION]
Displays whether the NDI | HX function is enabled. (Cannot be changed)
[‑‑] Not active.
[NDI | HX] Active.
[STREAMING FORMAT]
Specifies the streaming format.
