Panasonic AG-CX350 4K Camcorder - Manual (Page 67)

– 67 –
Chapter 4 Operation — Menu settings
[W.BAL PRESET]
Sets the color temperature to be assigned to the <PRST> position of the <WHITE BAL> switch.
The items that can be set are as follows.
f [3200K], [5600K], [VAR]
(Factory setting: [3200K])
[W.BAL VAR]
Sets the value of [VAR] in [W.BAL PRESET].
The setting can also be operated by the multidial button.
Enabled when [W.BAL PRESET] is set to [VAR] and the <WHITE BAL> switch is at <PRST>.
The items that can be set are as follows.
f [2000K]…[15000K]
(Factory setting: [3200K])
[H.ZOOM SPEED]
Sets the zoom speed of the handle zoom.
The items that can be set are as follows.
f [1]…[99]
(Factory setting: [50])
[i.ZOOM]
Keeps the image quality while performing digital zoom.
[ON] Enables the i.ZOOM function.
[OFF] Disables the i.ZOOM function.
(Factory setting: [OFF])
[MF ASSIST]
Sets whether to adjust the last focus automatically when in the manual focus mode.
If the image is largely out of focus, the focus may not be adjusted properly.
[ON] Adjusts the last focus automatically.
[OFF] Does not adjust the focus automatically.
(Factory setting: [OFF])
[MACRO]
Enables/disables the focus macro function.
If functions are assigned to the USER buttons, [ON]/[OFF] can be switched using the USER button operations.
[ON] Enables the focus macro function.
[OFF] Disables the focus macro function.
(Factory setting: [OFF])
[AF AREA WIDTH]
Adjusts the width of the area enable for the auto focus to match the size of the subject.
The items that can be set are as follows.
f [ON], [OFF]
(Factory setting: [OFF])
[A.IRIS SPEED]
Sets the control speed of the auto iris level function.
The items that can be set are as follows.
f [FAST], [NORMAL], [SLOW]
(Factory setting: [NORMAL])
[A.IRIS WINDOW]
Selects the auto iris detection window.
[NORMAL1] Window that is around center of the screen.
[NORMAL2] Window that is around bottom of the screen.
[CENTER] Window that is a spot around center of the screen.
(Factory setting: [NORMAL1])
[AREA MODE]
Assign the function that is performed within the area selected by touching the LCD monitor or pressing the < % > button, < ( > button, < ) > button,
or < = / & > button while shooting.
[INHIBIT] Disables assignment of functions.
[FOCUS] Assigns the auto focus function.
[IRIS] Assigns the auto iris function.
