– 171 –
Chapter 8 Connecting to External Devices — Connecting with headphones and TV/monitor
TV/monitor
A TV or monitor can be connected as shown in the following figure.
TV/monitor
BNC cable (optional)
HDMI cable (optional)
3.5 mm diameter video/audio cord 4-pole mini plug:
Commercial product
Audio (Left audio: White)
Video (Yellow)
Ground Audio (Right audio: Red)
@ @ NOTE
t VIERA Link is not supported on the camera. Note that the VIERA Link of other device may not properly operate when connected to the VIERA Link
compatible device with a HDMI cable (optional).
t The SD resolution signal output from the <HDMI> terminal is output as a progressive signal (480P, 576P).
t For the BNC cable (optional) connected to the <SDI OUT> terminal, prepare a double-shielded cable equivalent to 5C-FB.
t Use the double shielded cable supporting 4K/60P as the HDMI cable (optional). Also, it is recommended to use the Panasonic HDMI cable compatible
to 4K/60P as the HDMI cable.
