AMETEK ReFlex - Manual (Page 162)

ReFlex Power™ AC Power Supplies
M380056-01 Rev K 4-77
14. Set the output frequency to 500Hz
SOUR<n>:FREQ 500
15. Wait for AC current to stabilize. Measure the output current using the AC meter.
Enter the measured current using following command
CAL<n>:OUTP:FREQ:CURR2 <value-2>
16. Set the output frequency to 1000Hz
SOUR<n>:FREQ 1000
17. Wait for AC current to stabilize. Measure the output current using the AC meter.
Enter the measured current using following command
CAL<n>:OUTP:FREQ:CURR3 <value-3>
18. Set the output frequency to 2000Hz
SOUR<n>:FREQ 2000
19. Wait for AC current to stabilize. Measure the output current using the AC meter.
Enter the measured current using following command
CAL<n>:OUTP:FREQ:CURR4 <value-4>
20. Set the output frequency to 3000Hz
SOUR<n>:FREQ 3000
21. Wait for AC current to stabilize. Measure the output current using the AC meter.
Enter the measured current using following command
CAL<n>:OUTP:FREQ:CURR5 <value-5>
22. Set the output frequency to 4000Hz
SOUR<n>:FREQ 4000
23. Wait for AC current to stabilize. Measure the output current using the AC meter.
Enter the measured current using following command
CAL<n>:OUTP:FREQ:CURR6 <value-6>
24. Set the output frequency to 5000Hz
SOUR<n>:FREQ 5000
25. Wait for AC current to stabilize. Measure the output current using the AC meter.
Enter the measured current using following command
CAL<n>:OUTP:FREQ:CURR7 <value-7>
