ReFlex Power™ AC Power Supplies
M380056-01 Rev K 4-83
14. Set the output frequency to 250Hz
SOUR<n>:FREQ 250
15. Wait for AC current to stabilize. Measure the output current using the AC current
meter. Enter the measured current:
CAL<n>:OUTP:FREQ:CURR2 <value-2>
16. Set the output frequency to 440Hz
SOUR<n>:FREQ 440
17. Wait for AC current to stabilize. Measure the output current using the AC current
meter
CAL<n>:OUTP:FREQ:CURR3 <value-3>
18. Set the output frequency to 630Hz:
SOUR<n>:FREQ 630
19. Wait for AC current to stabilize. Measure the output current using the AC current
meter. Enter the measured current:
CAL<n>:OUTP:FREQ:CURR4 <value-4>
20. Set the output frequency to 820Hz:
SOUR<n>:FREQ 820
21. Wait for AC current to stabilize. Measure the output current using the AC current
meter. Enter the measured current using following command
CAL<n>:OUTP:FREQ:CURR5 <value-5>
22. Set the output frequency to 1010Hz
SOUR<n>:FREQ 1010
23. Wait for AC current to stabilize. Measure the output current using the AC current
meter. Enter the measured current using following command
CAL<n>:OUTP:FREQ:CURR6 <value-6>
24. Set the output frequency to 1200Hz:
SOUR<n>:FREQ 1200
25. Wait for AC current to stabilize. Measure the output current using the AC current
meter. Enter the measured current:
